MINI BALL VALVE provides flow control and isolation valve for pressure gauges and transmitters.
Specifications
Body
Forged Brass , SS
Gasket
Teflon
Connection
1/4“NPT Male x 1/4"NPT Female, 1/2" or other threads size available
Handle
Zinc plated steel, red plastic covered
Process Temperature
-9F to 212F (23C to 100C)
Maximum Operation Pressure
400Psi (2760 kPa)
